Realtime Chat Engineered

chat package

This article is a follow on from Realtime Chat with Vite, Vue3 and Python Tornado. In that article I suggested that I could provide a view of pylint, axblack, pytest and sphinx. I use Atom, but others are excellent too, such as VS Code, Eclipse and PyCharm. Atom has plug-ins to make it a usable python ide: language-python, python-black, linter-pylint, platformio-ide-terminal, to name but a few.

By engineering I mean tested, consistent, documented code. So let's start setting up some tools to make this less daunting.

In this artcile I'll be concentrating on python and cover javascript in another article when I address my appalling gui.

chat package

The tools:

To place these tools into our environment we'll adapt our use of pip. We'll create two files to express the development and production configurations of python: dev.txt and requirements.txt. Dev will be used by our Makefile and Requirements by our Dockerfile.

requirements.txt

tornado

dev.txt

-r requirements.txt invoke pytest pytest-coverage pytest-benchmark pytest-tornasync pylint axblack pyyaml sphinx recommonmark sphinx-autoapi bumpversion wheel twine nodeenv

NB. you should be putting version numbers beside these requirement packages. At the time of writing I was actually using tornado==6.1 - pip freeze will tell you what you've actually got. During development I leave them off so as to test for conflicts on the latest versions; if I find any, I lock down.

Makefile

setup: if which python3 && [ ! -d venv ] ; then python3 -m venv venv ; fi source venv/bin/activate \ && python -m pip install -q -U pip \ && pip install -r dev.txt \ && if [ ! -d nenv ] ; then nodeenv nenv; fi

We've told pip to use our dev.txt which includes our requirements.txt - no duplication wherever possible. By running make setup, your environment will be updated to contain the new packages.

Dockerfile

I alluded to docker in the previous article. It's simple to setup with two files: Dockerfile, docker-compose.yml. The first describes your container and the second enables you to run it locally.

FROM python:3-alpine as base FROM base as builder RUN mkdir /install WORKDIR /install COPY requirements.txt /requirements.txt RUN pip install --prefix=/install -r /requirements.txt FROM base COPY --from=builder /install /usr/local COPY . /app WORKDIR /app # Make port 80 available to the world outside this container EXPOSE 80 CMD ["python", "-m", "chat.main", "--port=80"]

Our Docker file uses multi-phase build to extend the base python image with our requirements.txt and then layered atop is our app. We expose a web port and specify our command to run the app.

docker-compose.yml

version: '3' services: web: build: . volumes: - .:/app image: chat:latest container_name: chat ports: - "8080:80" command: python -m chat.main --port=80 --debug=true

Here we declare our build and run-time environment. We map our project directory to our container's app directory for hot-reloading and map a local port to a container port so that our browsers can see the app. We also override the command with a debug option so we can see our changes should we make them.

To run the container: docker-compose build, followed by docker-compose up.

Invoke

Invoke is a marvellous tool for those who cannot remember command line interfaces. You can write simple macros to do all your dev tasks. Just create a tasks.py in the root of your project:

tasks.py

""" our dev tasks """ from invoke import task @task(help={'debug': 'run in hot-reload mode'}) def server(ctx, debug=False): """ run our python server """ ctx.run(f'python -m chat.main --debug={debug}') @task def client(ctx): """ run our vite server """ ctx.run('. nenv/bin/activate && cd client && npm run dev') @task def build(ctx): """ build our vue client """ ctx.run('. nenv/bin/activate && cd client && npm run build') @task def docker(ctx): """ build & run our docker server """ ctx.run('docker-compose build') ctx.run('docker-compose up')

Activate your venv and you run invoke -l or the short-cut inv -l. You'll see the help text.

% . venv/bin/activate % inv -l Available tasks: build build our vue client client run our vite server docker build & run our docker server server run our python server

Notice that invoke is self documenting - try inv --help server. If we run our server now, it has a flag option for debug so we can run in debug mode by calling inv server -d.

setup.cfg

Using all the tools we've installed we need to configure them. Each tool has its own config file, but most of them also look for setup.cfg.

[pylint.'MESSAGES CONTROL'] disable= too-few-public-methods, abstract-method [isort] line_length = 79 [tool:pytest] addopts = -p no:warnings --capture=sys --cov chat --cov-report term-missing filterwarnings = ignore::DeprecationWarning testpaths = tests

This file holds the configurations for pylint, axblack and pytest. So let's use pylint and axblack.

pylint & axblack

black is a wonderful tool. Type away and it will clean up after you. Sadly, black itself goes for double quotes only. We live in a json world and snippets live in single quotes. So axblack gives you the opinionation of black, but expects double quotes for comments and single quotes for code.

We just add a task to tasks.py:

@task def lint(ctx): """ run axblack and pylint """ ctx.run('black chat') ctx.run('pylint chat')

And to run it: inv lint. You should find unchanged files and 10.00/10! If not - fix it! Fixing it means either live with the badness and add to the setup.cfg and conform. Conforming is a contortion but following through I've found interesting changes to my code style, if nothing else.

pytest

Pytest is the swiss army knife of python testing tools. With the extension in our dev.txt we will be able to test, determine coverage and performance and we have helpers for tornado and async code.

First create a tests package and add a module: tests/conftests.py. This file will contain our fixtures - pytest's useful reusables for setting up tests.

conftests.py

""" our test fictures """ import pytest from tornado.httpclient import HTTPRequest from tornado.websocket import websocket_connect from chat.main import make_app @pytest.fixture def app(): """ return a tornado application """ return make_app() @pytest.fixture async def ws_client(http_server, http_server_port): """ return a websocket client """ request = HTTPRequest(f'ws://localhost:{http_server_port[1]}/ws') result = await websocket_connect(request) return result

We want to test our websocket and to do that we'll need an app fixture as required by pytest-tornasync. We also return the result of tornado's websocket_connect as documented here.

tests/test_ws.py

""" test websocket client """ import asyncio async def test_ws(ws_client): """ test message send and receive """ message = 'hello, world' client = await ws_client await client.write_message(message) response = await client.read_message() print(response) assert response == message client.close() await asyncio.sleep(0.01)

To run the test call:

% pytest

NB. Fixtures are functions and they are called as they are marshalled into your test's arguments. Since our ws_client is a coroutine we end up with an awaitable. In our async test we can await the result. Other fixtures do not need this extra step.

Our test is simple, we await our client, write a message, read a message and assert they are the same. Then we tidy up and... Our coverage is not 100%. First I #pragma nocover the chat.main.main function and the if __name__ == '__main__' because they are tested all the time - but we have one more edge case that is not covered - CORS. To do this we have to fake a call from another domain. So we add the following fixture to conftest.py:

@pytest.fixture async def ws_bad_client(http_server, http_server_port): """ return a websocket client """ request = HTTPRequest( f'ws://localhost:{http_server_port[1]}/ws', headers={'Origin': 'http://locahost:3000'}, ) result = await websocket_connect(request) return result

The add the following two tests to test_ws.py:

async def test_ws_cors_failure(ws_bad_client): """ test message send and receive """ try: await ws_bad_client assert False, 'should have returned 403' except HTTPClientError as ex: assert ex.code == 403 async def test_ws_cors_success(ws_bad_client, app): """ test message send and receive """ message = 'hello, world' app.settings['debug'] = True client = await ws_bad_client await client.write_message(message) response = await client.read_message() print(response) assert response == message client.close() await asyncio.sleep(0.01)

Now running the test should produce 100% coverage!

We'll create a task in tasks.py to help with our workflow.

@task def test(ctx): """ run our tests """ ctx.run('pytest')

Sphinx

Now that we can run and test our code, let's document it. Shinx is already in the dev.txt with some extension. To begin our sphinx project we'll call:

% mkdir docsrc % cd docsrc % sphinx quickstart

and answer all the questions (NB. defaults are good). First we have to add our extension to docsrc/conf.py:

extensions = [ 'sphinx.ext.autodoc', 'recommonmark', 'sphinx.ext.viewcode', 'autoapi.extension', ]

And at the bottom, configure our extensions, so add the following:

html_theme_options = {'logo': 'favicon.ico'} autoapi_dirs = ['../chat'] autoapi_type = 'python' autodoc_typehints = 'description' autoapi_add_toctree_entry = False

And copy your favicon into the docsrc/_static directory. To support github, we'll build to a docs directory, so we'll add a target to the docsrc/Makefile.

github: @make html @cp -a _build/html/. ../docs

Finally, let's edit the docsrc/index.rst to add our autoapi to the table of contents:

.. toctree:: :maxdepth: 2 :caption: Contents: chat <autoapi/chat/index>

Now we can add some tasks to task.py to make our docs.

@task def docs_build(ctx): """ build docs """ ctx.run('cd docsrc && make github') ctx.run('touch ./docs/.nojekll') @task def docs_server(ctx, port='8081'): """ run a server for the documents """ url = f'http://localhost:{port}' print(f'doc-server at: {url}') webbrowser.open(url) ctx.run( f'python3 -m http.server {port} --directory=./docsrc/_build/html/', pty=True, ) @task def cheatsheet(_): """ open the github rst-cheatsheet """ webbrowser.open( 'https://github.com/ralsina/rst-cheatsheet/blob/master/rst-cheatsheet.rst' )

To build call: inv docs-build. To see them, call: inv docs-server. Because I cannot rememeber syntax, I've added a cheatsheet task that provides help with rst syntax.

Don't forget to update the .gitignore and the .dockerignore to not include build directories and the remains of testing.

Finally

Let's bring it all together with our docker task.

@task(pre=[lint, build, test, docs_build]) def docker(ctx): """ build & run our docker server """ ctx.run('docker-compose build') ctx.run('docker-compose up') ctx.run('docker-compose down')

Calling inv docker will build, test it all, and then run the docker container. You should see the chat site at http://localhost:8080.

For every choice made here there are a myriad of alternatives available. These are merely the expression of what has stuck with me through my practice. As I continue to code, my nosiness and laziness will continue to evolve a combination of tools to say: "this is cool!" or "I couldn't be bothered".

Next time we'll add authentication and persistence with SQLAlchemy, and extend our Websocket to use json-rpc.

The source is on https://github.com/blueshed/chat/tree/article2
