KX080-4 - page 9

• Digital display panel
• Front window power-assisted with gas damper
• 12 V power source
• Front window guard mounting points
• 2 speakers and radio aerial
• Location for radio
• Cup holder
• Emergency exit hammer
Optional Equipment
Undercarriage
• 450 mm steel track (+ 50 kg)
Working equipment
• 1750 mm arm (- 22 kg)
Safety system
• Anti-drop valve unit on the dozer
Others
• Special paint upon request
• Light weight version (-195 kg)
• Beacon light
Safety system
• LH control lever console
• Travel motor with disc brake
• Swivel motor with disc brake
• Overload warning buzzer
• Kubota original anti-theft system
• Anti-drop valve on the boom (ISO8643)
• Anti-drop valve on the arm
• All hydraulic control
Working equipment
• Auxiliary hydraulic circuit piping to the arm end
• 2 working lights on cabin and 1 light on the boom
• 2100 mm arm
• Bracket and harness for beacon light
Cabin
• ROPS (Roll-over Protective Structure, ISO3471)
• FOPS (Falling Object Protective Structure) Level 1
•Weight-adjustable full suspension seat
• Retractable seatbelt
• Hydraulic pilot control levers with adjustable
wrist rests
• Travel levers with foot pedals
• Air conditioning
• Cabin heater for defrosting & demisting
Engine/Fuel system
• Double-element air filter
• Automatic fuel bleed system
• Auto idling system
• Tank electric refuelling pump
• Variable speed fan
•Water separator
Undercarriage
• (450 mm) rubber track
• 1 x upper track roller
• 5 single-flange track rollers on each track
• 2-speed travel switch on dozer lever
Hydraulic system
• Pressure accumulator
• Hydraulic pressure checking ports
• Third line hydraulic return with lever
• 3-pump load sensing system
• Adjustable maximum oil flow on auxiliary
hydraulic circuits (AUX1/AUX2)
• Auxiliary switch (AUX1) on right control lever
(proportional)
• Auxiliary switch (AUX2) on left control lever
(proportional)
• 2-speed travel with auto-shift
Standard Equipment
Kubota Original Anti-theft System
Your KX080-4 is protected by Kubota’s industry-leading
antitheft system. Only programmed keys will enable the engine
to start up. Attempting to start with an un-programmed key will
activate the alarm. Newly enhanced features include an alert to
remind the operator to extract the key after operation, and an
LED to alert potential thieves that the system is activated.
The red programming key programs
the individual keys. The individual
black keys start the engine.
Smooth Simultaneous
Operation
Kubota’s 2-piece boom offers reliably
smooth and fast performance. Its
innovative hydraulic mechanism enables
the operator to easily run the arm, boom,
bucket, and swivel simultaneously,
boosting work efficiency and increasing
productivity.
Easy Boom Control
The user-friendly design and location of
the 2-piece boom pedal makes operation
extremely simple. Located to the left of the
driving pedals, the operator simply needs
to flip the footpad, and depress the right
side of the pedal to extend the boom, or
the left side to retract it. This feature
greatly simplifies the footwork necessary
to smoothly operate the boom.
L
R
L
R
1,2,3,4,5,6,7,8 10,11,12
